All components that belongs to the electrical category like, LEDs, wires etc.
1.5mm Series AMP Superseal Waterproof Female Connector (Housing + Wire seal + Female Terminal)
AMP Superseal 1.5 series connector family to meet the increasing requirements for reliability in waterproof applications. The AMP Superseal 1.5 series connector exceeds the requirements prescribed by IP67 according IEC 60529 and DIN 40050-9 standards and has its application in automotive, agriculture, and industrial machinery. The AMP SUPERSEAL 1.5 series connector system is qualified for sensor applications as well.
1.5mm Series AMP Superseal Waterproof Male Connector (Housing + Wire seal + Male Terminal)
AMP Superseal 1.5 series connector family to meet the increasing requirements for reliability in waterproof applications. The AMP Superseal 1.5 series connector exceeds the requirements prescribed by IP67 according IEC 60529 and DIN 40050-9 standards and has its application in automotive, agriculture, and industrial machinery. The AMP SUPERSEAL 1.5 series connector system is qualified for sensor applications as well.
12 Volt DC Motor – 200 RPM
OVERVIEW
- Gear Material: Plastic
- Rated RPM: 500
- Operating Voltage(VDC): 12
- Rated Torque(kg-cm): 0.7
- Stall Torque(Kg-Cm): 3
- Load Current(A): 0.3
- No-Load Current: 60mA
- Gearbox Diameter (mm): 37
- Motor Diameter(mm): 32
- Motor Length(mm): 75
- Shaft Diameter (mm): 6
- Shaft Length (mm): 22
- Weight (gm): 80
150 RPM BO Motor- L Shape
OVERVIEW
- Operating Voltage(VDC): 3~12
- Shaft Length (mm): 8.5
- Shaft Diameter (mm): (Double D-type) 5.5
- No Load Current: 40-180mA.
- Rated Speed(After Reduction): 150
- Rated Torque: 0.8 kg-cm
- Weight (gm): 30
- Dimensions in mm (LxWxH): 42 x 55 x 22
- Gearbox Shape: L-Shape
150 RPM Single Shaft BO Motor – Straight
OVERVIEW
- Cost-effectiveness of the injection-molding process.
- Elimination of machining operations.
- Low density: lightweight, low inertia.
- Uniformity of parts.
17HS4401S Nema 1.7A 17 Stepper Motor
OVERVIEW
- Nema17 Bipolar.
- Number of Phase: 2.
- Phase Voltage: 2.6Vdc.
- Phase Current: 1.7A.
- Holding Torque: 43N.cm.
- Shaft Diameter: Ø5mm.
- Motor Length: 40mm.
2.54mm JST-SM Connector Male + Female +Terminal (pack of 5)
JST SM series is a 2.5 mm pitch, wire-to-wire connector that performs reliably in high-density, small current applications. It has high contact pressure and highly reliable housing construction. It can be mounted on a variety of panels and it also has an armlock mechanism.
2.5mm JST-XH Connector Male + Female +Terminal (pack of 5)
JST XH series is a 2.5 mm pitch, crimp-style connector that was developed based on the high reliability and versatility of their NH series connectors. The connector is very small with a mounting height of 9.8 mm. These wire-to-board connectors are typically used to bring power to a PC board. All XH series connectors are compliant with RoHS standards.
20Ah Li-ion Battery
CUSTOM BATTERY CAPACITY AVAILABLE
We also provide customized battery pack depending upon customer needs. Contact us for more details: support@toboids.com
24 V Hero Water Solenoid Valve
OVERVIEW
- Brand: Hero water
- Package Contains: 1 Solenoid Valve
- 24 V Hero Water Solenoid Valve Compatible With All Ro Water Purifiers
- Easily Fitted in All Models, No Breaking, no Leaking During Moving and Installing
- 24 V Dc, 0-120 Psi, 2.5 Mm Orifice
3.96mm JST-VH Connector Male + Female +Terminal (pack of 5)
JST-VH Connector With Housing is a small, field-proven connector for PC boards, it is reliable and has a large current carrying capacity. It can be used with a wide variety of signal, power supply, and output circuits that appear in consumer electronic products.
300 RPM Dual Shaft BO Motor-Straight
OVERVIEW
- Operating Voltage(VDC): 3~12
- Shaft Length (mm): 8.5
- Shaft Diameter (mm): 5.5
- No Load Current: 40-180mA.
- Rated Speed(After Reduction): 300 RPM
- Rated Torque: 0.35 Kgcm
- Weight (gm): 30
- Dimensions in mm (LxWxH): 70x35x22
- Gearbox Shape: Straight
