3D Touch Auto Leveling Sensor

2,690 incl. GST (exc. GST- 2,280 )

OVERVIEW
  • Voltage:5V
  • current :15mA
  • Max current 300mA
  • Shell material: PC
  • Shell color: White translucent

1 in stock

SKU: C02510 Category:
Description
Share

3D Printer TOUCH is an auto-leveling sensor for 3D Printers that can precisely measure the tilt of your print surface. It can greatly improve the printing precision of your 3D Printer.

The main functions and controls of 3D printer touch are the same as most auto bed leveling sensors, which consists of an RC servo and a micro switch, thus,3D printer touch can be used on almost every 3D printer control board.

By using progressively designed solenoid and hall sensors, It can integrate high precision in such a simple structure. To make it more user-friendly and to bring you more enjoyable printing experience.

SPECIFICATIONS



Voltage 5V
Current 15mA
Max. Current 300mA
Shell material PC
Shell color White translucent
Cable length 150mm
Dimension (mm) 200 x 200 x 0.5
Weight 10g



OPERATION CONDITION

  • 3DTouch can be operated in the following condition.
  • One I/O for control (PWM or Software PWM)
  • One I/O for Z min (Z Probe)
  • GND and +5V power

WIRE DESCRIPTION

3-pin: Brown (-, GND), Red (+5V), Orange (control signal)

2-pin: Black (-, GND), White (Z min)

FEATURES

  1. Simple, smart
  2. High-precision
  3. 3DTouch consists of Atmel ATtiny13A, solenoid, and a push pin.
  4. Innovative Solenoid: Ultra Power Saving
  5. It could work with nearly any kind of bed material, such as glasses, woods, metals, and so on.

PAKAGE INCLUDES

1 x 3D Touch Auto Leveling Sensor
